Wooden Reels 68mm
Dimensions
- 1700 x 700 x 1000
- 1800 x 900 x 1000
- 1900 x 900 x 1000
- 2000 x 1100 x 1000
- 2100 x 1100 x 1000
Features
- 6 Rods of 1/2″ and 12 Volts of 1/2″ – 3/4″
- 12 Embedded Steel Washers 55
- 2 Bushings of 200mm x 200mm
- Material: Pine/Saligna
TECHNICAL INFORMATION
Reels with Stave Inserts in the Flanges
Reel with reinforcement disk for the flanges and drum fitting according to IRAM 9051-1 standard
Visual Inspection of Knots
The wood is pre-selected to ensure that the drum receives wood without knots, positioning any potential knots in the reel flanges, and avoiding locations specified in Standard 9060, which refers to Standard IRAM 9590-1.
⦁ Internal edge of the reel’s tread band
⦁ External edge of the groove for stave fitting
⦁ Ends of the staves
⦁ Top (or working) edges of the staves
Visual Inspection of Cracks and Splits
This inspection eliminates wood with cracks wider than 2mm and longer than 250mm.
